Hannay Hose Reel 1016-14-16
Hannay Hose Reel 1016-14-16
Hannay 1000 Series Compact Manual Rewind Reels to handle single 1/4, 3/8 or 1/2 inch I.D. Hose.
Applications: Industrial, Construction, Spray, Pressure Wash, Grounds Maintenance, Lawn Care, Agriculture, Sewer, Waste, Transportation, Utilities, Processing, Marine
• Lightweight, compact with an e-coated frame
• Direct crank rewind permanently attached
• Adjustable cam-lock-brake standard
• Exterior mounting holes for easier installation
• Field installable pin lock
• Standard inlet: 90° ball bearing swivel, joint 1/2" female NPT threads
• Standard outlet: 3/8" female NPT threads
• Pressures to 3000 psi (207 bar)
• Temperatures from +20° F to +400° F (-7° C to +204° C)
• Consult mdi for other pressures and temperatures
Original: $254.95
-65%$254.95
$89.23
Description
Hannay Hose Reel 1016-14-16
Hannay 1000 Series Compact Manual Rewind Reels to handle single 1/4, 3/8 or 1/2 inch I.D. Hose.
Applications: Industrial, Construction, Spray, Pressure Wash, Grounds Maintenance, Lawn Care, Agriculture, Sewer, Waste, Transportation, Utilities, Processing, Marine
• Lightweight, compact with an e-coated frame
• Direct crank rewind permanently attached
• Adjustable cam-lock-brake standard
• Exterior mounting holes for easier installation
• Field installable pin lock
• Standard inlet: 90° ball bearing swivel, joint 1/2" female NPT threads
• Standard outlet: 3/8" female NPT threads
• Pressures to 3000 psi (207 bar)
• Temperatures from +20° F to +400° F (-7° C to +204° C)
• Consult mdi for other pressures and temperatures
